Power Jacks Neeter Drive U-serie Bevel Gear Box

Neeter Drive U-serie Bevel Gear Box

The Power Jacks subsea range has been developed for a diversity of industries and are used worldwide. The sectors vary from subsea to oil and gas and even submerged nuclear applications.

When you are selecting a gearbox there are a number of factors that will impact your choice and the final size of the subsea bevel gearbox. Power Jacks has set up a 12 step process that uses the following application information to select the right gearbox.

• Bevel Gearbox Input Speed (rpm)
• Bevel Gearbox Output Speed (rpm)
• Bevel Gearbox configuration
• Required Output Torque (Nm)
• Operating Hours per day
• Input Power Source Bevel Gearbox application
• Number of starts per hour
• Transmission methods
• Duty cycle per hour (% running time)
• Operating ambient temperature

Technical specifications of the U-serie Bevel Gear Box

• Subsea Bevel Gearbox Design
• Proven depth ratings up to 3000m subsea (deeper on request)
• Pressure compensated or flooded designs available
• 2-way, 3-way or 4-way shaft configurations
• Solid Shaft or Hollow shaft designs
• Gear Ratios: 1:1, 1.5:1, 2:1, 3:1, 4:1 as standard
• Special gear ratios available on request e.g. 1.25:1
• Torque Ratings up to 20000 Nm
• Option for reinforced shaft design for up to 300% higher torque transmission
• Full stainless steel designs available- Reinforced sealing
• Full range of anti-corrosion options
• ROV drive interfaces
• Low (-65°C) to High (+250°C) temperature solutions available
• Vibration and shock load resistant designs
• Full range of feedback devices for speed, position and rotation monitoring control
• Special custom designs available to meet your exact requirements
