Uni M-TTB

Uni M-TTB | straight running

The uni M-TTB is a belt for use in all types of packages, food and non-food industries. The sides have slanted edges for good lateral transitions and are strong and reliable due to the rigidity of the links. Small transition between the jobs and high speeds are possible thanks to the small pitch.

The UltraClean Two-Part sprockets can be used in combination with this modulair belt

• Nominal pitch: 12,7 mm
• Pin diameter: 4 mm (closed)
• Possibilites: 37% open surface
• Straight running, Straight transport, 2 running directions.
• FDA, USDA approved
• Trouble-free transitions possible thanks to the RIB version and finger plates. Many applications possible (Multi-use).
• Sprockets: ø 49,1 – 145,7 mm.
• Belt width: 77 – 1844 mm. (308mm. = Singlelink)
• Brand: Unichains

Due to our large assortment, there is almost always a product that is suitable for your applications. We not only supply transport components, but also all the other products needed to achieve an optimal process. In our stockpile we have, for example, various types of drive technology, hydraulic components, oil coolers and our own monitoring system the Beegle. Do you want to know more about a product or do you have a question? Our specialized sales engineers will be happy to assist you in finding the best product needed for you technical challenge. Feel free to contact us if you have questions or seek information.
