CLAMPEX KTR 400 clamping set

CLAMPEX KTR 400:

self-centering internal clamping sets

Self-centering clamping element with utmost performance data

The CLAMPEX® KTR 400 self-centering internal clamping set is a backlash-free clamping element.

These clamping sets allow for a backlash-free and frictionally engaged connection between cylindrical shafts without keyway and hub bores (shaft-hub-connection).

The self-centering internal clamping set CLAMPEX KTR 400 has the longest mounting length compared to other internal clamping sets, thus transmits the highest forces.

Additional centering between shaft and hub is not necessary.

During assembly there is an axial displacement of hub to shaft.

Clampex internal, self-centering, clamping sets

With the self-centering internal clamping sets (shaft-hub-connection) the centering of hub to shaft is made by the clamping set. In this way additional centering of the hub is not necessary.

CLAMPEX self-centering internal clamping sets allow for a backlash-free and frictionally engaged connection between cylindrical shafts without keyway and hub bores.

The wedge-shaped components of the clamping sets that are shifted on top of each other via clamping screws generate radial forces that provide for friction fit on the contact surfaces of shaft and hub bores.

This friction fit allows for simultaneous transmission of torque and axial force. The integrated clamping screws are used for clamping and untightening of the clamping sets depending on the type of clamping set.

CLAMPEX internal clamping sets are preferred, among other things, as an alternative to a feather key connection considering their benefits.
