RIMOSTAT®-Torque Limiters RSHD

RIMOSTAT®-Torque Limiters RSHD

The contact pressure on the friction surfaces is produced by long coil springs. Because of the RIMOSTAT® Torque Limiter’s linear, flat-angle characteristic of the pressure force, practically no reduction of the slipping torque occurs even when friction linings are subjected to wear. As the diagram 68-3 shows, compared
with Belleville spring torque limiters, assuming friction wear of Δf the reduction of the slipping torque ΔM is negligible.

Features

• Better stability of slipping torque than Belleville spring torque limiters over the duration of the operating period
• Adjustment of slipping torque setting according to the number of active springs – not through modification of spring pressure
• Superb wear-behavior during high energy-input
• High temperature resistant
• Nickel-free friction pads
